> 60°C de-rate power by 2.5% / °C (when battery is fully charged) If the battery is not fully charged at max load, it is recommended that the surrounding air temperature should not exceed 50°C.
运行湿度
5 to 95% RH (Non-Condensing)
防震测试（非运行状态）
IEC 60068-2-27, 30 G (300 m/s²) for a duration of 18 ms, 1 time per direction, 2 times in total
振动测试（非运行状态）
IEC 60068-2-6, 10 Hz to 500 Hz @ 30 m/s² (3 G peak); 60 min per axis for all X, Y, Z direction
储藏湿度
-
运行高度
0 to 6,000 m (Approvals apply only up to 5,000 m)
污染程度
2
碰撞试验（运行状态）
-
过压类别
-
Corrosion
-
过压保护
Auto Recovery
超负载/过电保护
Normal Operation: Auto Recovery Battery Operation: Latch off
过热保护
Normal Operation: Auto Recovery Battery Operation: Latch off
短路保护
Buffering Mode: Shutdown, Latch Mode
极性反接保护
-
防护等级
IP20
防震保护
Class III
输入端极性保护
Yes
电池极性保护
Yes
电池电压保护错误
Yes, 30 Vdc Max (the maximum voltage that will not cause damage to the unit)
深度放电保护
Yes (21 V typ.)
超负载保护
-
过电保护
-
内置保险丝
-
输入欠压保护
Yes
MTBF
> 500,000 hrs. as per Telcordia SR-332
预计最长使用寿命
-
Safety Certificate
-
电气安全
CB scheme: IEC 62368-1 TUV Bauart: EN 62368-1 UL/cUL recognized: UL 62368-1 and CAN/CSA C22.2 No. 62368-1 (File No. E131881) EAC: TP TC 002/2011
CE
In conformance with EMC Directive 2014/30/EU and Low Voltage Directive 2014/35/EU
医疗安全
-
电隔离
Power Port to Housing: 500 Vac Signal Port to Housing: 500 Vac Power Port to Signal Port: 500 Vac
工业控制设备
-
危险场所/ATEX
-
II 3 G ATEX 2014/34/EU
-
机器电气设备
-
用於电率安装的电气设备
-
安全特低电压
-
海事
-
材料与部件
-
隔离电阻
-
PE 电阻
-
UKCA
In conformance with Electromagnetic Compatibility Regulations 2016 and Electrical Equipment (Safety) Regulations 2016
国家地区证书
-
BIS
-
KC
-
Electrical Equipment for Measurement, Control, and Laboratory Use
-
ITE Safety
-
SIL3
-
排放
CE & RE EN/BS EN 61000-6-4, EN 61204-3
抗扰度
EN/BS EN 61000-6-2, EN 61204-3
谐波电流排放
-
电压波动和闪变
-
ESD 抗扰度
-
辐射抗扰度
-
EFT
-
电涌
-
传导抗扰度
-
磁场
-
电压骤降
-
通用用途之部件供电
EN 61204-3
额定电池电压
24 Vdc, SLA Sealed lead acid battery 2 x 12 Vdc, SLA Sealed lead acid battery in series
电池电压范围
21-27.6Vdc (continuously operating) 30Vdc Max (the maximum voltage that will not cause damage to the unit) 19.2Vdc Min (the voltage level of battery tol enable “Repl. BAT.” relay contact. (DRU module will not charge the battery)
电池容量
3.4 AH ~ 100 AH
电池充电模式
1 A, 2 A, 3 A, 4 A (typ.) (constant current)
充电电压结束
27.6 V
电池熔断器
2 pcs in parallel; LITTELFUSE: 0257030. PXAPC, BUSSMANN: ATC-30 or equivalent (for DRN-24V7AAEN)
电池放电电压范围
21 Vdc ... 27.6 Vdc 30 Vdc Max (the maximum voltage that will not cause damage to the unit)
