Delta PMT-36V100W2BA 36V 108W 3A Panel Mount PMT2 Series

Model	Description
PMT-36V100W2BAB	Single side conformal coating

Model	Description
PMT-36V100W2BAB	Single side conformal coating

Download

Datasheet

Uploaded on 02-Apr-2024

Manual

Uploaded on 06-May-2024


Uploaded on 06-Jun-2024

Mechanical Drawing

Uploaded on 15-May-2020

.DXF

Uploaded on 22-Apr-2020

.STP

Uploaded on 22-Apr-2020

Certificates

BSMI

Uploaded on 22-Jul-2021

Uploaded on 16-Jan-2023

CCC

Uploaded on 24-Jan-2024

CE & UKCA

Uploaded on 21-Jun-2021

EAC

Uploaded on 22-Apr-2020

REACH

Uploaded on 08-May-2024

RoHS

Uploaded on 27-May-2024

TSCA

Uploaded on 15-Nov-2023

TUV

Uploaded on 02-Jun-2020

Uploaded on 10-Aug-2021

GUI Software

Tech Specs

Output Current

Output Voltage

36V

Output Voltage Adjustment Range

32.4-39.6Vdc

Output Power

108W

Line Regulation

± 0.5% (@ 115Vac & 230Vac input)

Load Regulation

± 0.5% (@ 115Vac & 230Vac input)

PARD

< 200mVpp @ 0°C to 70°C, 600mVpp typ. @ -30°C to 0°C

Start-up Time

500ms typ. @ 115Vac & 230Vac (100% load)

Hold-up Time

9ms typ. @ 115Vac, 42ms typ. @ 230Vac

Dynamic Response (Overshoot & Undershoot O/P Voltage)

± 10% @ 115 & 230Vac input, 10-100% load (Slew Rate: 2.5A/μS, 50% duty cycle @ 5Hz & 10KHz)

Start-up with Capacitive Loads

3,000µF Max

Rise Time

30ms typ. @ 115Vac & 230Vac

Nominal Input Voltage

100-240Vac

Input Voltage Range

90-264Vac

Nominal Input Frequency

50-60Hz

Input Frequency Range

47-63Hz

Input Current

1.9A typ. @ 115Vac, 1.2A typ. @ 230Vac

Efficiency at 100% load

91.0% typ. @ 230Vac

Inrush Current

55A typ. @ 230Vac (Cold Start)

Leakage Current

< 0.5mA @ 240Vac

Case Chassis / Cover Aluminium / SGCC
Indicator Green LED (DC OK)
Cooling System Convection
Input Terminal -
Output Terminal -
Signal Terminal -
Noise Sound Pressure Level (SPL) -
Input/Output Terminal -
Signal -
Mounting Rail -
Wire Wire AWG 18-12 Current rating can refer to page 6 “Wire AWG Table”
Protection Structure -
Terminal -
Unit Weight 0.285 kg (0.63 lb)	Dimensions 129 x 97 x 30 mm 5.08” x 3.82” x 1.18”

Vibration (Operating)

IEC 60068-2-6, Sine Wave: 20Hz to 500Hz (5G);
10min per cycle, 60min for each axis (X, Y,Z)

Shock Test (Operating)

IEC 60068-2-27, Half Sine Wave: 10G for a duration of 11ms, 3 shock for each 3 directions.

Operating Temperature

-30°C to +70°C (-40°C Cold Start)

Storage Temperature

-40°C to +85°C

Power De-rating

> 50°C de-rate power by 2% / °C
< 115Vac de-rate power by 0.6% / V
(85% load @ 90Vac)

Operating Humidity

20 to 90% RH (Non-Condensing)

Shock Test (Non-Operating)

IEC 60068-2-27, Half Sine Wave: 50G for a duration of 11ms, 3 shocks for each 3 directions

Vibration (Non-Operating)

IEC 60068-2-6, Random: 5Hz to 500Hz (2.09G);
20 min per axis for all X, Y, Z direction

Operating Altitude

0 to 5,000 Meters (16,400 ft.)

Pollution Degree

Over Voltage Category

II (Compliance to EN 62477-1 OVC III with 2000 meters altitude)

Overvoltage

39.6V-48.6V SELV Output, Latch Mode

Overload / Overcurrent

110-175% of rated load current, Hiccup Mode, Non-Latching (Auto-Recovery)

Over Temperature

Latch Mode

Short Circuit

Hiccup Mode, Non-Latching (Auto-Recovery when the fault is removed)

Protection Against Shock

Class I with PE*4 connection

MTBF

> 700,000 hrs as per Telcordia SR-332
I/P: 230Vac, O/P: 100% Load, Ta: 25°C)

Expected Cap Life Time

10 years (230Vac, 50% load @ 40°C)

Electrical Safety

TUV Bauart: EN 62368-1, EN60335-1, EN 61558-1/-2-16
cULus: UL 62368-1 and CAN/CSA C22.2 No. 62368-1
CB scheme: IEC 62368-1, IEC 60950-1, IEC 60335-1, IEC 61558-1/-2-16
KC: K 60950-1
EAC: TP TC 004/2011
BSMI: CNS 14336-1

In conformance with EMC Directive 2014/30/EU and Low Voltage Directive 2014/35/EU

Galvanic Isolation

Input to Output:4.0 KVac
Input to Ground: 2.0 KVac
Output to Ground:1.25 KVac

Safety Entry Low Voltage

SELV

UKCA

In conformance with Electromagnetic Compatibility Regulations 2016 and Electrical Equipment (Safety) Regulations 2016

Emission

(CE & RE)
CISPR 32, EN/BS EN 55032, EN/BS EN 61000-6-4, KN32, AS/NZS CISPR32
Compliance to EN/BS EN 55014-1, FCC Title 47, EN/BS EN 61000-6-3 : Class B

Immunity

EN/BS EN 55035, KN35, EN/BS EN 61000-6-2
Compliance to EN/BS EN 55014-2,EN/BS EN 61000-6-1

Harmonic Current Emissions

IEC/EN/BS EN 61000-3-2, Class A
