EUCO-1K5140GLA

LED電源

EUCO ARENA SPORT 系列

EUCO-1K5140GLA

輸出電壓

260-500V

輸出功率

1500W

輸出電流

1.4A

輸入電壓範圍

198-440Vac

尺寸 (L x W x H)

500 x 152 x 77 mm

19.69” x 5.98” x 3.03”

重量

5.6 kg (12.35 lb)

亮點與特色
  • Dimmable built-in constant current 3-channel LED Driver with DALI 2
  • Each channel independently programmable with output channels max output power of 500W (1500W total)
  • Adjustable output current between 500mA to 1400 mA for each channel via I-programming tool
  • Very low pk–pk current ripple to 1% for stadium lighting
  • Dimming range 0.1% to 100 %
  • Max remote distance 200 meters
  • In compliance with Erp (EU) 2019/2020
Model Description
EUCO-1K5140GDA Control Interface: RDM/DMX
應用領域


EUCO-1K5140GLA
EUCO-1K5140GLA

LED電源

EUCO ARENA SPORT 系列

EUCO-1K5140GLA

亮點與特色
  • Dimmable built-in constant current 3-channel LED Driver with DALI 2
  • Each channel independently programmable with output channels max output power of 500W (1500W total)
  • Adjustable output current between 500mA to 1400 mA for each channel via I-programming tool
  • Very low pk–pk current ripple to 1% for stadium lighting
  • Dimming range 0.1% to 100 %
  • Max remote distance 200 meters
  • In compliance with Erp (EU) 2019/2020
輸出電壓

260-500V

輸出功率

1500W

輸出電流

1.4A

輸入電壓範圍

198-440Vac

尺寸

500 x 152 x 77 mm

19.69” x 5.98” x 3.03”

重量

5.6 kg (12.35 lb)

應用領域
Model Description
EUCO-1K5140GDA Control Interface: RDM/DMX

資源下載

資源下載

Datasheet

Uploaded on 24-Oct-2023

Manual

Uploaded on 21-Feb-2022


Uploaded on 05-Jun-2024

Mechanical Drawing

Uploaded on 11-Aug-2020

.STP

Uploaded on 07-Jun-2022

CB

Uploaded on 30-Jun-2020

CE

Uploaded on 30-Jun-2020

ENEC

Uploaded on 30-Jun-2020

GUI Program

Uploaded on 27-Sep-2024

Tech Specs

Tech Specs
