LNA-600A20AFCDA

LED電源

LNA ARENA SPORT 系列

LNA-600A20AFCDA

輸出電壓

200-550V

輸出功率

600W

輸出電流

輸入電壓範圍

198-440Vac

尺寸 (L x W x H)

285 x 100 x 49 mm

11.22” x 3.94” x 1.93”

重量

2.2 kg (4.85 lb)

亮點與特色

Output power: max 600W

Wide input voltage: 198-440VAC

Ultra high Efficiency 97.5%

Control method: RDM/DMX

Programmable output current range 700-2000 mA

Constant Light Output (CLO) function

Smart Timer Dimming (STD)

Wide dimming range 0.1-100%

High-accuracy integrated power metering

Input surge protection: DM 6kV; CM 10kV

Max signal control distance 300 meters

Reliable IP66 input/output connectors

Low current ripple (typ.1%) for HDTV broadcasting

Afterglow effect free

應用領域

資源下載

Datasheet

Uploaded on 11-Mar-2025


Uploaded on 16-Jun-2025

Mechanical Drawing

Uploaded on 11-Mar-2025

.DXF

Uploaded on 11-Mar-2025

認證

Uploaded on 10-Mar-2025

CCC

Uploaded on 10-Mar-2025

Uploaded on 12-Mar-2025

ENEC

Uploaded on 10-Mar-2025

RCM

Uploaded on 10-Mar-2025

UKCA

Uploaded on 12-Mar-2025

GUI Software

GUI Program

Uploaded on 17-Jan-2025

Tech Specs

輸出電流

輸出電壓

200-550V

輸出電壓範圍

200-550Vdc

輸出功率

600W

輸出電流調整範圍

0.7-2A

最大輸出電壓

600Vdc

額定輸入電壓

220-400Vac

輸入電壓範圍

198-440Vac

額定輸入頻率

50-60Hz

輸入頻率範圍

47-63Hz

輸入電流

2.85 A At 220 Vac, 25°C, 600 W output
1.54 A At 400 Vac, 25°C, 600 W output

輸入功率（備用電源模式）

0.40 W At 230 Vac/50 Hz, Dim OFF, in compliance with Erp (EU) 2019/2020
0.89 W At 400 Vac, Dim OFF

100% 負載效率

96.2% At 220 Vac, 25°C, 300 V/2 A
96.6% At 220 Vac, 25°C, 550 V/1.1 A
96.8% At 400 Vac, 25°C, 300 V/2 A output
97.5% At 400 Vac, 25°C, 550 V/1.1 A output

浪湧電流

8A At 220 Vac，50% Apk to 50% Apk time: 2 ms
15A At 400 Vac，50% Apk to 50% Apk time: 2 ms

功率因數

0.99 At 220 Vac, 25°C, 600 W output
0.98 At 400 Vac, 25°C, 600 W output

諧波失真總量

8% At 220 Vac, 25°C, 300 V/2 A output
13% At 400 Vac, 25°C, 300 V/2 A output

底架 / 外殼 Aluminum case, color: anodized (Nature)
指示燈 -
冷卻方式 Natural Convection
輸入端 Line(L): Brown, Neutral(N): Blue, PE: Yellow & Green, SOOW & H07RN-F & 2PNCT, 3C/1.0 mm² (17AWG), Length: 300mm±25mm
輸出端 Positive(V+): Brown, Negative(V-): Blue, PE: Yellow & Green, SOOW & H07RN-F & 2PNCT, 3C/1.0 mm² (17AWG), Length: 240mm±25mm
信號端 -
聲壓級（SPL） < 24dBA at 30cm distance
輸入/輸出端 -
信號 -
安裝導軌 -
電線 -
保護結構 -
端子台 -
重量 2.2 kg (4.85 lb)	尺寸 285 x 100 x 49 mm 11.22” x 3.94” x 1.93”

運行溫度

-40 ~+60°C

儲存溫度

-40°C to +85°C

運行濕度

10% to 90% RH (Non-Condensing)

振動測試（非運行狀態）

IEC 60068-2-6, Random: 5 Hz to 10 Hz (1G);
30 min per axis for all X, Y, Z direction

儲藏濕度

10% to 90% RH (Non-Condensing)

防護等級

IP66

MTBF

475 khrs at Ta=+45°C Telcordia SR-332

預計最長使用壽命

50,000 hours applicable for 220 Vac to 400 Vac(50/60 Hz) @100% of load, @ Ta 45°C

Safety Certificate

ENEC:
EN 61347-2-13:2014, EN 61347-2-13/A1:2017
EN 61347-1:2015, EN 61347-1:2015/A1:2021
EN IEC 62384:2020

RCM:
AS 61347-2-13: 2018
AS/NZS 61347-1: 2016+A1

CB report: EN 61347-1:2015, EN 61347-1:2015/A1:2021
EN 61347-2-13:2014, EN 61347-2-13/A1:2017

CCC: GB 19510.1, GB 19510.14

CE Declaration of Conformity

UKCA

BS EN 61347-2-13: 2014+A1:2017

輻射與傳導

Radiated Emission: EN55015, GB/T17743
Conducted Emission: EN55015, GB/T17743

諧波電流排放

EN61000-3-2, GB 17625.1

電壓波動和閃變

EN61000-3-3

ESD 抗擾度

EN 61000-4-2

EFT

EN 61000-4-4

電湧

(AC Mains)
EN 61000-4-5
- Common Mode: 10kV (Line to Earth, Neutral to Earth)
- Differential Mode: 6kV (Line to Neutral)

磁場

EN 61000-4-3

電壓驟降

EN 61000-4-11
