> 60°C de-rate power by 2.5% / °C (when battery is fully charged) If the battery is not fully charged at max load, it is recommended that the surrounding air temperature should not exceed 50°C.
运行湿度
5 to 95% RH (Non-Condensing)
防震测试（非运行状态）
IEC 60068-2-27, 30 G (300 m/s²) for a duration of 18 ms, 1 time per direction, 2 times in total
振动测试（非运行状态）
IEC 60068-2-6, 10 Hz to 500 Hz @ 30 m/s² (3 G peak); 60 min per axis for all X, Y, Z direction
储藏湿度
-
运行高度
0 to 6,000 m (Approvals apply only up to 5,000 m)
污染程度
2
碰撞试验（运行状态）
-
过压类别
-
Corrosion
-
过压保护
Auto Recovery
超负载/过电保护
Normal Operation: Auto Recovery Battery Operation: Latch off
过热保护
Normal Operation: Auto Recovery Battery Operation: Latch off
短路保护
-
极性反接保护
-
防护等级
IP20
防震保护
Class III
输入端极性保护
Yes
电池极性保护
Yes
电池电压保护错误
Yes, 30 Vdc Max (the maximum voltage that will not cause damage to the unit)
深度放电保护
Yes (21 V typ.)
超负载保护
-
过电保护
-
内置保险丝
-
输入欠压保护
Yes
MTBF
> 500,000 hrs. as per Telcordia SR-332
预计最长使用寿命
-
Safety Certificate
-
电气安全
CB scheme: IEC 62368-1 TUV Bauart: EN 62368-1 UL/cUL recognized: UL 62368-1 and CAN/CSA C22.2 No. 62368-1 (File No. E131881) EAC: TP TC 002/2011
CE
In conformance with EMC Directive 2014/30/EU and Low Voltage Directive 2014/35/EU
医疗安全
-
电隔离
Power Port to Housing: 500 Vac Signal Port to Housing: 500 Vac Power Port to Signal Port: 500 Vac
工业控制设备
-
危险场所/ATEX
-
II 3 G ATEX 2014/34/EU
-
机器电气设备
-
用於电率安装的电气设备
-
安全特低电压
-
海事
-
材料与部件
-
隔离电阻
-
PE 电阻
-
UKCA
In conformance with Electromagnetic Compatibility Regulations 2016 and Electrical Equipment (Safety) Regulations 2016
国家地区证书
-
BIS
-
KC
-
Electrical Equipment for Measurement, Control, and Laboratory Use
-
ITE Safety
-
SIL3
-
排放
CE & RE EN/BS EN 61000-6-4, EN 61204-3
抗扰度
EN/BS EN 61000-6-2, EN 61204-3
谐波电流排放
-
电压波动和闪变
-
ESD 抗扰度
-
辐射抗扰度
-
EFT
-
电涌
-
传导抗扰度
-
磁场
-
电压骤降
-
通用用途之部件供电
-
额定电池电压
24 Vdc, SLA Sealed lead acid battery 2 x 12 Vdc, SLA Sealed lead acid battery in series
电池电压范围
-
电池容量
3.4 AH ~ 100 AH
电池充电模式
-
充电电压结束
27.6 V
电池熔断器
-
电池放电电压范围
21 Vdc ... 27.6 Vdc 30 Vdc Max (the maximum voltage that will not cause damage to the unit)
电池充电电流
0.75 A, 1.5 A, 2.25 A, 3 A (typ.) (constant current)
