Convection Linear power de-rate from 100% load at 50°C, to 53.3% load at 70°C Force Air Linear power de-rate from 100% load at 50°C, to 50% load at 70°C
运行湿度
5-95% RH (Non-Condensing)
防震测试（非运行状态）
50 G, 11 ms, 3 shocks for each direction
振动测试（非运行状态）
-
储藏湿度
-
运行高度
Up to 5,000 meters (up to 16,400 feet or 106-54 kPa)
污染程度
-
碰撞试验（运行状态）
-
过压类别
-
Corrosion
-
过压保护
Main output 140% of rated normal voltage, Latch Mode Standby 125% of rated voltage, Latch Mode
超负载/过电保护
750 W for over 750 ms max Standby 3.2 A max with Hiccup Mode(Non-Latching, Auto-Recovery)
过热保护
Latch Mode for Main output
短路保护
Hiccup Mode for Main output and Standby (Non-Latching, Auto-Recovery)
极性反接保护
-
防护等级
-
防震保护
-
输入端极性保护
-
电池极性保护
-
电池电压保护错误
-
深度放电保护
-
超负载保护
-
过电保护
-
内置保险丝
-
输入欠压保护
-
MTBF
500 Khrs based on Telecordia SR-332
预计最长使用寿命
26,280 hrs
Safety Certificate
IEC60601-1 CB report TUV EN60601-1 A11/A12 CAN/CSA-C22.2 No. 60601-1 + ANSI/AAMI ES 60601-1 IEC60950-1 CB report IEC62368-1 CB report TUV EN62368-1 UL62368-1 and CAN/CSA C22.2 No. 62368-1 IEC60335-1 CB report (12 V & 24 V Model) TUV EN60335-1 (12 V & 24 V Model) IEC61558-1 CB report (12 V & 24 V Model) TUV EN61558-1/-2-16 (12 V & 24 V Model)
