EUCI-130105GLB

LED Driver

EUCI LITE Series

EUCI-130105GLB

Output Voltage

60-200V

Output Power

130W

Output Current

0.2-1.05A

Input Voltage Range

198-264Vac

Dimensions (L x W x H)

150.0 x 90.0 x 40.0 mm

5.91” x 3.54” x 1.57”

Unit Weight

0.75 (0.00 lb)

Highlights & Features

DALI-2 certified LED driver, 5%-100 % dimming range
Flexible configurable operating windows (AOC) via NFC, DALI
Robustness protection against vibration, harsh operating temperature and moisture
Autonomous dimming includes three “Smart Timer Dim” operation modes with five independent levels
High Efficiency (Up to 90%)
High surge immunity
Design and fix for luminaires of protection class I and protection class II

Applications

LED Driver

EUCI LITE Series

EUCI-130105GLB

Highlights & Features

DALI-2 certified LED driver, 5%-100 % dimming range
Flexible configurable operating windows (AOC) via NFC, DALI
Robustness protection against vibration, harsh operating temperature and moisture
Autonomous dimming includes three “Smart Timer Dim” operation modes with five independent levels
High Efficiency (Up to 90%)
High surge immunity
Design and fix for luminaires of protection class I and protection class II

Output Voltage

60-200V

Output Power

130W

Output Current

0.2-1.05A

Input Voltage Range

198-264Vac

Dimensions

150.0 x 90.0 x 40.0 mm

5.91” x 3.54” x 1.57”

Unit Weight

0.75 (0.00 lb)

Applications

Download

Datasheet

Uploaded on 15-Nov-2024


Uploaded on 15-Nov-2024

Mechanical Drawing

Uploaded on 11-Nov-2024

.DXF

Uploaded on 15-Nov-2024

.STP

Uploaded on 15-Nov-2024

Certificates

Uploaded on 15-Nov-2024

Uploaded on 08-Oct-2024

ENEC

Uploaded on 15-Nov-2024

UKCA

Uploaded on 08-Oct-2024

GUI Software

GUI Program

Uploaded on 08-Oct-2024

Tech Specs

Output Current

0.2-1.05A

Output Voltage

60-200V

Output Voltage Range

60-200Vdc

Output Power

130W

Max Output Voltage

230Vdc

Line Regulation

± 3% (@ 220-240Vac)

Load Regulation

± 5% (@ Min-Max output voltage)

Start-up Time

520~1000ms max. (@ 220-240Vac)

Nominal Input Voltage

220-240Vac

Input Voltage Range

198-264Vac

Nominal Input Frequency

50-60Hz

Input Frequency Range

47-63Hz

Input Current

0.67A @ 230Vac

Efficiency at 100% load

93% @ 0.7A, 230Vac
92% @ 1.05A, 230Vac

Inrush Current

50A/250uS @ 230Vac

Power Factor at 100% load

> 0.95 @ 230Vac, 100% load

Leakage Current

< 0.7mA peak @ 230Vac

Total Harmonic Distortion

< 10% @ 230Vac, 100% load

Case Chassis / Cover Plastic, Color : Black
Indicator -
Cooling System Convection
Input Terminal -
Output Terminal -
Signal Terminal -
Noise Sound Pressure Level (SPL) < 24dBA
Input/Output Terminal -
Signal -
Mounting Rail -
Wire -
Protection Structure -
Terminal -
Unit Weight 0.75 (0.00 lb)	Dimensions 150.0 x 90.0 x 40.0 mm 5.91” x 3.54” x 1.57”

Operating Temperature

-40°C to +55°C

Storage Temperature

-40°C to +85°C

Operating Humidity

10 to 90% RH (Non-Condensing)

Storage Humidity

5 to 95% RH (Non-Condensing)

Overvoltage

350Vrms, Luminaries will work normally when the fault is removed

Overload / Overcurrent

Reduce output current. Auto-Recovery when the fault is removed

Over Temperature

Reduce output current. Auto-Recovery when the fault is removed

Short Circuit

Auto-Recovery when the fault is removed

Degree of Protection

IP20

MTBF

100,000 hours @ lifetime case temperature

Expected Cap Life Time

690,000 hours @Ta=+55°C (as per Telcordia SR-332, total failure rate less than10%)

Safety Certificate

IEC 61347-1, IEC 61347-2-13 (Built in)
EN 61347-1, EN 61347-2-13

Electrical Safety

IEC 61347-1, IEC 61347-2-13 (Built in)
EN 61347-1, EN 61347-2-13

In conformance with EMC Directive and Low Voltage Directive

Material and Parts

RoHS Directive 2011/65/EU Compliant

Emission

(CE & RE)
Compliance to EN 55015 Class B

Immunity

Compliance to EN 61547

Harmonic Current Emissions

Class C (230Vac @ ≥ 50% load)
