Hiccup Mode, Non-Latching (Auto-Recovery when the fault is removed)
极性反接保护
-
防护等级
-
防震保护
Class I with Primary Earth connection
输入端极性保护
-
电池极性保护
-
电池电压保护错误
-
深度放电保护
-
超负载保护
-
过电保护
-
内置保险丝
-
输入欠压保护
-
MTBF
> 500,000 hrs. as per Telcordia SR-332 I/P: 115Vac, O/P: 100% load, Ta: 25°C
预计最长使用寿命
10 years (115Vac & 230Vac, 50% load @ 40°C)
Safety Certificate
-
电气安全
SIQ Bauart: EN 62368-1 cCSAus: CSA C22.2 No. 250.13 and UL 8750 CSA C22.2 No. 60950-1 and UL 60950-1 CSA C22.2 No. 62368-1 and UL 62368-1 CB scheme: IEC 60950-1, IEC 62368-1, IEC 61347-1 and IEC 61347-2-13
CE
In conformance with EMC Directive 2014/30/EU and Low Voltage Directive 2014/35/EU
医疗安全
-
电隔离
Input to Output 4kVac (Reinforced) 3kVac (Production Test) Input to Ground 1.5kVac (Basic & Production Test) Output to Ground 1.5kVac (Basic)
工业控制设备
-
危险场所/ATEX
-
II 3 G ATEX 2014/34/EU
-
机器电气设备
-
用於电率安装的电气设备
-
安全特低电压
SELV (IEC 60950-1)
海事
-
材料与部件
-
隔离电阻
-
PE 电阻
-
UKCA
In conformance with Electromagnetic Compatibility Regulations 2016 and Electrical Equipment (Safety) Regulations 2016
国家地区证书
-
BIS
-
KC
-
Electrical Equipment for Measurement, Control, and Laboratory Use
-
ITE Safety
-
SIL3
-
排放
Generic Standards: CISPR 32, EN/BS EN 55032: Class B
抗扰度
Generic Standards: EN/BS EN 55024, EN/BS EN 55035
谐波电流排放
IEC/EN/BS EN 61000-3-2, Class C
电压波动和闪变
IEC/EN/BS EN 61000-3-3 at nominal voltages and full load
